热电电压单位为毫伏
˚C -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 ˚C



-260 -9.835 -9.833 -9.831 -9.828 -9.825 -9.821 -9.817 -9.813 -9.808 -9.802 -9.797 -260
-250 -9.797 -9.79 -9.784 -9.777 -9.77 -9.762 -9.754 -9.746 -9.737 -9.728 -9.718 -250
-240 -9.718 -9.709 -9.698 -9.688 -9.677 -9.666 -9.654 -9.642 -9.63 -9.617 -9.604 -240
-230 -9.604 -9.591 -9.577 -9.563 -9.548 -9.534 -9.519 -9.503 -9.487 -9.471 -9.455 -230
-220 -9.455 -9.438 -9.421 -9.404 -9.386 -9.368 -9.35 -9.331 -9.313 -9.293 -9.274 -220
-210 -9.274 -9.254 -9.234 -9.214 -9.193 -9.172 -9.151 -9.129 -9.107 -9.085 -9.063 -210
-200 -9.063 -9.04 -9.017 -8.994 -8.971 -8.947 -8.923 -8.899 -8.874 -8.85 -8.825 -200
-190 -8.825 -8.799 -8.774 -8.748 -8.722 -8.696 -8.669 -8.643 -8.616 -8.588 -8.561 -190
-180 -8.561 -8.533 -8.505 -8.477 -8.449 -8.42 -8.391 -8.362 -8.333 -8.303 -8.273 -180
-170 -8.273 -8.243 -8.213 -8.183 -8.152 -8.121 -8.09 -8.059 -8.027 -7.995 -7.963 -170
-160 -7.963 -7.931 -7.899 -7.866 -7.833 -7.8 -7.767 -7.733 -7.7 -7.666 -7.632 -160
-150 -7.632 -7.597 -7.563 -7.528 -7.493 -7.458 -7.423 -7.387 -7.351 -7.315 -7.279 -150
-140 -7.279 -7.243 -7.206 -7.17 -7.133 -7.096 -7.058 -7.021 -6.983 -6.945 -6.907 -140
-130 -6.907 -6.869 -6.831 -6.792 -6.753 -6.714 -6.675 -6.636 -6.596 -6.556 -6.516 -130
-120 -6.516 -6.476 -6.436 -6.396 -6.355 -6.314 -6.273 -6.232 -6.191 -6.149 -6.107 -120
-110 -6.107 -6.065 -6.023 -5.981 -5.939 -5.896 -5.853 -5.81 -5.767 -5.724 -5.681 -110
-100 -5.681 -5.637 -5.593 -5.549 -5.505 -5.461 -5.417 -5.372 -5.327 -5.282 -5.237 -100
-90 -5.237 -5.192 -5.147 -5.101 -5.055 -5.009 -4.963 -4.917 -4.871 -4.824 -4.777 -90
-80 -4.777 -4.731 -4.684 -4.636 -4.589 -4.542 -4.494 -4.446 -4.398 -4.35 -4.302 -80
-70 -4.302 -4.254 -4.205 -4.156 -4.107 -4.058 -4.009 -3.96 -3.911 -3.861 -3.811 -70
-60 -3.811 -3.761 -3.711 -3.661 -3.611 -3.561 -3.51 -3.459 -3.408 -3.357 -3.306 -60
-50 -3.306 -3.255 -3.204 -3.152 -3.1 -3.048 -2.996 -2.944 -2.892 -2.84 -2.787 -50
-40 -2.787 -2.735 -2.682 -2.629 -2.576 -2.523 -2.469 -2.416 -2.362 -2.309 -2.255 -40
-30 -2.255 -2.201 -2.147 -2.093 -2.038 -1.984 -1.929 -1.874 -1.82 -1.765 -1.709 -30
-20 -1.709 -1.654 -1.599 -1.543 -1.488 -1.432 -1.376 -1.32 -1.264 -1.208 -1.152 -20
-10 -1.152 -1.095 -1.039 -0.982 -0.925 -0.868 -0.811 -0.754 -0.697 -0.639 -0.582 -10
0 -0.582 -0.524 -0.466 -0.408 -0.35 -0.292 -0.234 -0.176 -0.117 -0.059 0 0
0 0 0.059 0.118 0.176 0.235 0.294 0.354 0.413 0.472 0.532 0.591 0
10 0.591 0.651 0.711 0.77 0.83 0.89 0.95 1.01 1.071 1.131 1.192 10
20 1.192 1.252 1.313 1.373 1.434 1.495 1.556 1.617 1.678 1.74 1.801 20
30 1.801 1.862 1.924 1.986 2.047 2.109 2.171 2.233 2.295 2.357 2.42 30
40 2.42 2.482 2.545 2.607 2.67 2.733 2.795 2.858 2.921 2.984 3.048 40
50 3.048 3.111 3.174 3.238 3.301 3.365 3.429 3.492 3.556 3.62 3.685 50
60 3.685 3.749 3.813 3.877 3.942 4.006 4.071 4.136 4.2 4.265 4.33 60
70 4.33 4.395 4.46 4.526 4.591 4.656 4.722 4.788 4.853 4.919 4.985 70
80 4.985 5.051 5.117 5.183 5.249 5.315 5.382 5.448 5.514 5.581 5.648 80
90 5.648 5.714 5.781 5.848 5.915 5.982 6.049 6.117 6.184 6.251 6.319 90
100 6.319 6.386 6.454 6.522 6.59 6.658 6.725 6.794 6.862 6.93 6.998 100
110 6.998 7.066 7.135 7.203 7.272 7.341 7.409 7.478 7.547 7.616 7.685 110
120 7.685 7.754 7.823 7.892 7.962 8.031 8.101 8.17 8.24 8.309 8.379 120
130 8.379 8.449 8.519 8.589 8.659 8.729 8.799 8.869 8.94 9.01 9.081 130
140 9.081 9.151 9.222 9.292 9.363 9.434 9.505 9.576 9.647 9.718 9.789 140
150 9.789 9.86 9.931 10.003 10.074 10.145 10.217 10.288 10.36 10.432 10.503 150
160 10.503 10.575 10.647 10.719 10.791 10.863 10.935 11.007 11.08 11.152 11.224 160
170 11.224 11.297 11.369 11.442 11.514 11.587 11.66 11.733 11.805 11.878 11.951 170
180 11.951 12.024 12.097 12.17 12.243 12.317 12.39 12.463 12.537 12.61 12.684 180
190 12.684 12.757 12.831 12.904 12.978 13.052 13.126 13.199 13.273 13.347 13.421 190
200 13.421 13.495 13.569 13.644 13.718 13.792 13.866 13.941 14.015 14.09 14.164 200
210 14.164 14.239 14.313 14.388 14.463 14.537 14.612 14.687 14.762 14.837 14.912 210
220 14.912 14.987 15.062 15.137 15.212 15.287 15.362 15.438 15.513 15.588 15.664 220
230 15.664 15.739 15.815 15.89 15.966 16.041 16.117 16.193 16.269 16.344 16.42 230
240 16.42 16.496 16.572 16.648 16.724 16.8 16.876 16.952 17.028 17.104 17.181 240
250 17.181 17.257 17.333 17.409 17.486 17.562 17.639 17.715 17.792 17.868 17.945 250
260 17.945 18.021 18.098 18.175 18.252 18.328 18.405 18.482 18.559 18.636 18.713 260
270 18.713 18.79 18.867 18.944 19.021 19.098 19.175 19.252 19.33 19.407 19.484 270
280 19.484 19.561 19.639 19.716 19.794 19.871 19.948 20.026 20.103 20.181 20.259 280
290 20.259 20.336 20.414 20.492 20.569 20.647 20.725 20.803 20.88 20.958 21.036 290
300 21.036 21.114 21.192 21.27 21.348 21.426 21.504 21.582 21.66 21.739 21.817 300
310 21.817 21.895 21.973 22.051 22.13 22.208 22.286 22.365 22.443 22.522 22.6 310
320 22.6 22.678 22.757 22.835 22.914 22.993 23.071 23.15 23.228 23.307 23.386 320
330 23.386 23.464 23.543 23.622 23.701 23.78 23.858 23.937 24.016 24.095 24.174 330
340 24.174 24.253 24.332 24.411 24.49 24.569 24.648 24.727 24.806 24.885 24.964 340
˚C 0 1 2 3 4 5 6 7 8 9 10 ˚C
˚C 0 1 2 3 4 5 6 7 8 9 10 ˚C
350 24.964 25.044 25.123 25.202 25.281 25.36 25.44 25.519 25.598 25.678 25.757 350
360 25.757 25.836 25.916 25.995 26.075 26.154 26.233 26.313 26.392 26.472 26.552 360
370 26.552 26.631 26.711 26.79 26.87 26.95 27.029 27.109 27.189 27.268 27.348 370
380 27.348 27.428 27.507 27.587 27.667 27.747 27.827 27.907 27.986 28.066 28.146 380
390 28.146 28.226 28.306 28.386 28.466 28.546 28.626 28.706 28.786 28.866 28.946 390
400 28.946 29.026 29.106 29.186 29.266 29.346 29.427 29.507 29.587 29.667 29.747 400
410 29.747 29.827 29.908 29.988 30.068 30.148 30.229 30.309 30.389 30.47 30.55 410
420 30.55 30.63 30.711 30.791 30.871 30.952 31.032 31.112 31.193 31.273 31.354 420
430 31.354 31.434 31.515 31.595 31.676 31.756 31.837 31.917 31.998 32.078 32.159 430
440 32.159 32.239 32.32 32.4 32.481 32.562 32.642 32.723 32.803 32.884 32.965 440
450 32.965 33.045 33.126 33.207 33.287 33.368 33.449 33.529 33.61 33.691 33.772 450
460 33.772 33.852 33.933 34.014 34.095 34.175 34.256 34.337 34.418 34.498 34.579 460
470 34.579 34.66 34.741 34.822 34.902 34.983 35.064 35.145 35.226 35.307 35.387 470
480 35.387 35.468 35.549 35.63 35.711 35.792 35.873 35.954 36.034 36.115 36.196 480
490 36.196 36.277 36.358 36.439 36.52 36.601 36.682 36.763 36.843 36.924 37.005 490
500 37.005 37.086 37.167 37.248 37.329 37.41 37.491 37.572 37.653 37.734 37.815 500
510 37.815 37.896 37.977 38.058 38.139 38.22 38.3 38.381 38.462 38.543 38.624 510
520 38.624 38.705 38.786 38.867 38.948 39.029 39.11 39.191 39.272 39.353 39.434 520
530 39.434 39.515 39.596 39.677 39.758 39.839 39.92 40.001 40.082 40.163 40.243 530
540 40.243 40.324 40.405 40.486 40.567 40.648 40.729 40.81 40.891 40.972 41.053 540
550 41.053 41.134 41.215 41.296 41.377 41.457 41.538 41.619 41.7 41.781 41.862 550
560 41.862 41.943 42.024 42.105 42.185 42.266 42.347 42.428 42.509 42.59 42.671 560
570 42.671 42.751 42.832 42.913 42.994 43.075 43.156 43.236 43.317 43.398 43.479 570
580 43.479 43.56 43.64 43.721 43.802 43.883 43.963 44.044 44.125 44.206 44.286 580
590 44.286 44.367 44.448 44.529 44.609 44.69 44.771 44.851 44.932 45.013 45.093 590
600 45.093 45.174 45.255 45.335 45.416 45.497 45.577 45.658 45.738 45.819 45.9 600
610 45.9 45.98 46.061 46.141 46.222 46.302 46.383 46.463 46.544 46.624 46.705 610
620 46.705 46.785 46.866 46.946 47.027 47.107 47.188 47.268 47.349 47.429 47.509 620
630 47.509 47.59 47.67 47.751 47.831 47.911 47.992 48.072 48.152 48.233 48.313 630
640 48.313 48.393 48.474 48.554 48.634 48.715 48.795 48.875 48.955 49.035 49.116 640
650 49.116 49.196 49.276 49.356 49.436 49.517 49.597 49.677 49.757 49.837 49.917 650
660 49.917 49.997 50.077 50.157 50.238 50.318 50.398 50.478 50.558 50.638 50.718 660
670 50.718 50.798 50.878 50.958 51.038 51.118 51.197 51.277 51.357 51.437 51.517 670
680 51.517 51.597 51.677 51.757 51.837 51.916 51.996 52.076 52.156 52.236 52.315 680
690 52.315 52.395 52.475 52.555 52.634 52.714 52.794 52.873 52.953 53.033 53.112 690
700 53.112 53.192 53.272 53.351 53.431 53.51 53.59 53.67 53.749 53.829 53.908 700
710 53.908 53.988 54.067 54.147 54.226 54.306 54.385 54.465 54.544 54.624 54.703 710
720 54.703 54.782 54.862 54.941 55.021 55.1 55.179 55.259 55.338 55.417 55.497 720
730 55.497 55.576 55.655 55.734 55.814 55.893 55.972 56.051 56.131 56.21 56.289 730
740 56.289 56.368 56.447 56.526 56.606 56.685 56.764 56.843 56.922 57.001 57.08 740
750 57.08 57.159 57.238 57.317 57.396 57.475 57.554 57.633 57.712 57.791 57.87 750
760 57.87 57.949 58.028 58.107 58.186 58.265 58.343 58.422 58.501 58.58 58.659 760
770 58.659 58.738 58.816 58.895 58.974 59.053 59.131 59.21 59.289 59.367 59.446 770
780 59.446 59.525 59.604 59.682 59.761 59.839 59.918 59.997 60.075 60.154 60.232 780
790 60.232 60.311 60.39 60.468 60.547 60.625 60.704 60.782 60.86 60.939 61.017 790
800 61.017 61.096 61.174 61.253 61.331 61.409 61.488 61.566 61.644 61.723 61.801 800
810 61.801 61.879 61.958 62.036 62.114 62.192 62.271 62.349 62.427 62.505 62.583 810
820 62.583 62.662 62.74 62.818 62.896 62.974 63.052 63.13 63.208 63.286 63.364 820
830 63.364 63.442 63.52 63.598 63.676 63.754 63.832 63.91 63.988 64.066 64.144 830
840 64.144 64.222 64.3 64.377 64.455 64.533 64.611 64.689 64.766 64.844 64.922 840
850 64.922 65 65.077 65.155 65.233 65.31 65.388 65.465 65.543 65.621 65.698 850
860 65.698 65.776 65.853 65.931 66.008 66.086 66.163 66.241 66.318 66.396 66.473 860
870 66.473 66.55 66.628 66.705 66.782 66.86 66.937 67.014 67.092 67.169 67.246 870
880 67.246 67.323 67.4 67.478 67.555 67.632 67.709 67.786 67.863 67.94 68.017 880
890 68.017 68.094 68.171 68.248 68.325 68.402 68.479 68.556 68.633 68.71 68.787 890
900 68.787 68.863 68.94 69.017 69.094 69.171 69.247 69.324 69.401 69.477 69.554 900
910 69.554 69.631 69.707 69.784 69.86 69.937 70.013 70.09 70.166 70.243 70.319 910
920 70.319 70.396 70.472 70.548 70.625 70.701 70.777 70.854 70.93 71.006 71.082 920
930 71.082 71.159 71.235 71.311 71.387 71.463 71.539 71.615 71.692 71.768 71.844 930
940 71.844 71.92 71.996 72.072 72.147 72.223 72.299 72.375 72.451 72.527 72.603 940
950 72.603 72.678 72.754 72.83 72.906 72.981 73.057 73.133 73.208 73.284 73.36 950
960 73.36 73.435 73.511 73.586 73.662 73.738 73.813 73.889 73.964 74.04 74.115 960
970 74.115 74.19 74.266 74.341 74.417 74.492 74.567 74.643 74.718 74.793 74.869 970
980 74.869 74.944 75.019 75.095 75.17 75.245 75.32 75.395 75.471 75.546 75.621 980
990 75.621 75.696 75.771 75.847 75.922 75.997 76.072 76.147 76.223 76.298 76.373 990
˚C 0 1 2 3 4 5 6 7 8 9 10 ˚C
