热电电压单位为毫伏
˚C -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 ˚C



-260 -6.458 -6.457 -6.456 -6.455 -6.453 -6.452 -6.45 -6.448 -6.446 -6.444 -6.441 -260
-250 -6.441 -6.438 -6.435 -6.432 -6.429 -6.425 -6.421 -6.417 -6.413 -6.408 -6.404 -250
-240 -6.404 -6.399 -6.393 -6.388 -6.382 -6.377 -6.37 -6.364 -6.358 -6.351 -6.344 -240
-230 -6.344 -6.337 -6.329 -6.322 -6.314 -6.306 -6.297 -6.289 -6.28 -6.271 -6.262 -230
-220 -6.262 -6.252 -6.243 -6.233 -6.223 -6.213 -6.202 -6.192 -6.181 -6.17 -6.158 -220
-210 -6.158 -6.147 -6.135 -6.123 -6.111 -6.099 -6.087 -6.074 -6.061 -6.048 -6.035 -210
-200 -6.035 -6.021 -6.007 -5.994 -5.98 -5.965 -5.951 -5.936 -5.922 -5.907 -5.891 -200
-190 -5.891 -5.876 -5.861 -5.845 -5.829 -5.813 -5.797 -5.78 -5.763 -5.747 -5.73 -190
-180 -5.73 -5.713 -5.695 -5.678 -5.66 -5.642 -5.624 -5.606 -5.588 -5.569 -5.55 -180
-170 -5.55 -5.531 -5.512 -5.493 -5.474 -5.454 -5.435 -5.415 -5.395 -5.374 -5.354 -170
-160 -5.354 -5.333 -5.313 -5.292 -5.271 -5.25 -5.228 -5.207 -5.185 -5.163 -5.141 -160
-150 -5.141 -5.119 -5.097 -5.074 -5.052 -5.029 -5.006 -4.983 -4.96 -4.936 -4.913 -150
-140 -4.913 -4.889 -4.865 -4.841 -4.817 -4.793 -4.768 -4.744 -4.719 -4.694 -4.669 -140
-130 -4.669 -4.644 -4.618 -4.593 -4.567 -4.542 -4.516 -4.49 -4.463 -4.437 -4.411 -130
-120 -4.411 -4.384 -4.357 -4.33 -4.303 -4.276 -4.249 -4.221 -4.194 -4.166 -4.138 -120
-110 -4.138 -4.11 -4.082 -4.054 -4.025 -3.997 -3.968 -3.939 -3.911 -3.882 -3.852 -110
-100 -3.852 -3.823 -3.794 -3.764 -3.734 -3.705 -3.675 -3.645 -3.614 -3.584 -3.554 -100
-90 -3.554 -3.523 -3.492 -3.462 -3.431 -3.4 -3.368 -3.337 -3.306 -3.274 -3.243 -90
-80 -3.243 -3.211 -3.179 -3.147 -3.115 -3.083 -3.05 -3.018 -2.986 -2.953 -2.92 -80
-70 -2.92 -2.887 -2.854 -2.821 -2.788 -2.755 -2.721 -2.688 -2.654 -2.62 -2.587 -70
-60 -2.587 -2.553 -2.519 -2.485 -2.45 -2.416 -2.382 -2.347 -2.312 -2.278 -2.243 -60
-50 -2.243 -2.208 -2.173 -2.138 -2.103 -2.067 -2.032 -1.996 -1.961 -1.925 -1.889 -50
-40 -1.889 -1.854 -1.818 -1.782 -1.745 -1.709 -1.673 -1.637 -1.6 -1.564 -1.527 -40
-30 -1.527 -1.49 -1.453 -1.417 -1.38 -1.343 -1.305 -1.268 -1.231 -1.194 -1.156 -30
-20 -1.156 -1.119 -1.081 -1.043 -1.006 -0.968 -0.93 -0.892 -0.854 -0.816 -0.778 -20
-10 -0.778 -0.739 -0.701 -0.663 -0.624 -0.586 -0.547 -0.508 -0.47 -0.431 -0.392 -10
0 -0.392 -0.353 -0.314 -0.275 -0.236 -0.197 -0.157 -0.118 -0.079 -0.039 0 0
0 0 0.039 0.079 0.119 0.158 0.198 0.238 0.277 0.317 0.357 0.397 0
10 0.397 0.437 0.477 0.517 0.557 0.597 0.637 0.677 0.718 0.758 0.798 10
20 0.798 0.838 0.879 0.919 0.96 1 1.041 1.081 1.122 1.163 1.203 20
30 1.203 1.244 1.285 1.326 1.366 1.407 1.448 1.489 1.53 1.571 1.612 30
40 1.612 1.653 1.694 1.735 1.776 1.817 1.858 1.899 1.941 1.982 2.023 40
50 2.023 2.064 2.106 2.147 2.188 2.23 2.271 2.312 2.354 2.395 2.436 50
60 2.436 2.478 2.519 2.561 2.602 2.644 2.685 2.727 2.768 2.81 2.851 60
70 2.851 2.893 2.934 2.976 3.017 3.059 3.1 3.142 3.184 3.225 3.267 70
80 3.267 3.308 3.35 3.391 3.433 3.474 3.516 3.557 3.599 3.64 3.682 80
90 3.682 3.723 3.765 3.806 3.848 3.889 3.931 3.972 4.013 4.055 4.096 90
100 4.096 4.138 4.179 4.22 4.262 4.303 4.344 4.385 4.427 4.468 4.509 100
110 4.509 4.55 4.591 4.633 4.674 4.715 4.756 4.797 4.838 4.879 4.92 110
120 4.92 4.961 5.002 5.043 5.084 5.124 5.165 5.206 5.247 5.288 5.328 120
130 5.328 5.369 5.41 5.45 5.491 5.532 5.572 5.613 5.653 5.694 5.735 130
140 5.735 5.775 5.815 5.856 5.896 5.937 5.977 6.017 6.058 6.098 6.138 140
150 6.138 6.179 6.219 6.259 6.299 6.339 6.38 6.42 6.46 6.5 6.54 150
160 6.54 6.58 6.62 6.66 6.701 6.741 6.781 6.821 6.861 6.901 6.941 160
170 6.941 6.981 7.021 7.06 7.1 7.14 7.18 7.22 7.26 7.3 7.34 170
180 7.34 7.38 7.42 7.46 7.5 7.54 7.579 7.619 7.659 7.699 7.739 180
190 7.739 7.779 7.819 7.859 7.899 7.939 7.979 8.019 8.059 8.099 8.138 190
200 8.138 8.178 8.218 8.258 8.298 8.338 8.378 8.418 8.458 8.499 8.539 200
210 8.539 8.579 8.619 8.659 8.699 8.739 8.779 8.819 8.86 8.9 8.94 210
220 8.94 8.98 9.02 9.061 9.101 9.141 9.181 9.222 9.262 9.302 9.343 220
230 9.343 9.383 9.423 9.464 9.504 9.545 9.585 9.626 9.666 9.707 9.747 230
240 9.747 9.788 9.828 9.869 9.909 9.95 9.991 10.031 10.072 10.113 10.153 240
˚C 0 1 2 3 4 5 6 7 8 9 10 ˚C
800 33.275 33.316 33.357 33.398 33.439 33.48 33.521 33.562 33.603 33.644 33.685 800
810 33.685 33.726 33.767 33.808 33.848 33.889 33.93 33.971 34.012 34.053 34.093 810
820 34.093 34.134 34.175 34.216 34.257 34.297 34.338 34.379 34.42 34.46 34.501 820
830 34.501 34.542 34.582 34.623 34.664 34.704 34.745 34.786 34.826 34.867 34.908 830
840 34.908 34.948 34.989 35.029 35.07 35.11 35.151 35.192 35.232 35.273 35.313 840
850 35.313 35.354 35.394 35.435 35.475 35.516 35.556 35.596 35.637 35.677 35.718 850
860 35.718 35.758 35.798 35.839 35.879 35.92 35.96 36 36.041 36.081 36.121 860
870 36.121 36.162 36.202 36.242 36.282 36.323 36.363 36.403 36.443 36.484 36.524 870
880 36.524 36.564 36.604 36.644 36.685 36.725 36.765 36.805 36.845 36.885 36.925 880
890 36.925 36.965 37.006 37.046 37.086 37.126 37.166 37.206 37.246 37.286 37.326 890
900 37.326 37.366 37.406 37.446 37.486 37.526 37.566 37.606 37.646 37.686 37.725 900
910 37.725 37.765 37.805 37.845 37.885 37.925 37.965 38.005 38.044 38.084 38.124 910
920 38.124 38.164 38.204 38.243 38.283 38.323 38.363 38.402 38.442 38.482 38.522 920
930 38.522 38.561 38.601 38.641 38.68 38.72 38.76 38.799 38.839 38.878 38.918 930
940 38.918 38.958 38.997 39.037 39.076 39.116 39.155 39.195 39.235 39.274 39.314 940
950 39.314 39.353 39.393 39.432 39.471 39.511 39.55 39.59 39.629 39.669 39.708 950
960 39.708 39.747 39.787 39.826 39.866 39.905 39.944 39.984 40.023 40.062 40.101 960
970 40.101 40.141 40.18 40.219 40.259 40.298 40.337 40.376 40.415 40.455 40.494 970
980 40.494 40.533 40.572 40.611 40.651 40.69 40.729 40.768 40.807 40.846 40.885 980
990 40.885 40.924 40.963 41.002 41.042 41.081 41.12 41.159 41.198 41.237 41.276 990
1000 41.276 41.315 41.354 41.393 41.431 41.47 41.509 41.548 41.587 41.626 41.665 1000
1010 41.665 41.704 41.743 41.781 41.82 41.859 41.898 41.937 41.976 42.014 42.053 1010
1020 42.053 42.092 42.131 42.169 42.208 42.247 42.286 42.324 42.363 42.402 42.44 1020
1030 42.44 42.479 42.518 42.556 42.595 42.633 42.672 42.711 42.749 42.788 42.826 1030
1040 42.826 42.865 42.903 42.942 42.98 43.019 43.057 43.096 43.134 43.173 43.211 1040
1050 43.211 43.25 43.288 43.327 43.365 43.403 43.442 43.48 43.518 43.557 43.595 1050
1060 43.595 43.633 43.672 43.71 43.748 43.787 43.825 43.863 43.901 43.94 43.978 1060
1070 43.978 44.016 44.054 44.092 44.13 44.169 44.207 44.245 44.283 44.321 44.359 1070
1080 44.359 44.397 44.435 44.473 44.512 44.55 44.588 44.626 44.664 44.702 44.74 1080
1090 44.74 44.778 44.816 44.853 44.891 44.929 44.967 45.005 45.043 45.081 45.119 1090
˚C 0 1 2 3 4 5 6 7 8 9 10 ˚C
˚C 0 1 2 3 4 5 6 7 8 9 10 ˚C
250 10.153 10.194 10.235 10.276 10.316 10.357 10.398 10.439 10.48 10.52 10.561 250
260 10.561 10.602 10.643 10.684 10.725 10.766 10.807 10.848 10.889 10.93 10.971 260
270 10.971 11.012 11.053 11.094 11.135 11.176 11.217 11.259 11.3 11.341 11.382 270
280 11.382 11.423 11.465 11.506 11.547 11.588 11.63 11.671 11.712 11.753 11.795 280
290 11.795 11.836 11.877 11.919 11.96 12.001 12.043 12.084 12.126 12.167 12.209 290
300 12.209 12.25 12.291 12.333 12.374 12.416 12.457 12.499 12.54 12.582 12.624 300
310 12.624 12.665 12.707 12.748 12.79 12.831 12.873 12.915 12.956 12.998 13.04 310
320 13.04 13.081 13.123 13.165 13.206 13.248 13.29 13.331 13.373 13.415 13.457 320
330 13.457 13.498 13.54 13.582 13.624 13.665 13.707 13.749 13.791 13.833 13.874 330
340 13.874 13.916 13.958 14 14.042 14.084 14.126 14.167 14.209 14.251 14.293 340
350 14.293 14.335 14.377 14.419 14.461 14.503 14.545 14.587 14.629 14.671 14.713 350
360 14.713 14.755 14.797 14.839 14.881 14.923 14.965 15.007 15.049 15.091 15.133 360
370 15.133 15.175 15.217 15.259 15.301 15.343 15.385 15.427 15.469 15.511 15.554 370
380 15.554 15.596 15.638 15.68 15.722 15.764 15.806 15.849 15.891 15.933 15.975 380
390 15.975 16.017 16.059 16.102 16.144 16.186 16.228 16.27 16.313 16.355 16.397 390
400 16.397 16.439 16.482 16.524 16.566 16.608 16.651 16.693 16.735 16.778 16.82 400
410 16.82 16.862 16.904 16.947 16.989 17.031 17.074 17.116 17.158 17.201 17.243 410
420 17.243 17.285 17.328 17.37 17.413 17.455 17.497 17.54 17.582 17.624 17.667 420
430 17.667 17.709 17.752 17.794 17.837 17.879 17.921 17.964 18.006 18.049 18.091 430
440 18.091 18.134 18.176 18.218 18.261 18.303 18.346 18.388 18.431 18.473 18.516 440
450 18.516 18.558 18.601 18.643 18.686 18.728 18.771 18.813 18.856 18.898 18.941 450
460 18.941 18.983 19.026 19.068 19.111 19.154 19.196 19.239 19.281 19.324 19.366 460
470 19.366 19.409 19.451 19.494 19.537 19.579 19.622 19.664 19.707 19.75 19.792 470
480 19.792 19.835 19.877 19.92 19.962 20.005 20.048 20.09 20.133 20.175 20.218 480
490 20.218 20.261 20.303 20.346 20.389 20.431 20.474 20.516 20.559 20.602 20.644 490
500 20.644 20.687 20.73 20.772 20.815 20.857 20.9 20.943 20.985 21.028 21.071 500
510 21.071 21.113 21.156 21.199 21.241 21.284 21.326 21.369 21.412 21.454 21.497 510
520 21.497 21.54 21.582 21.625 21.668 21.71 21.753 21.796 21.838 21.881 21.924 520
530 21.924 21.966 22.009 22.052 22.094 22.137 22.179 22.222 22.265 22.307 22.35 530
540 22.35 22.393 22.435 22.478 22.521 22.563 22.606 22.649 22.691 22.734 22.776 540
550 22.776 22.819 22.862 22.904 22.947 22.99 23.032 23.075 23.117 23.16 23.203 550
560 23.203 23.245 23.288 23.331 23.373 23.416 23.458 23.501 23.544 23.586 23.629 560
570 23.629 23.671 23.714 23.757 23.799 23.842 23.884 23.927 23.97 24.012 24.055 570
580 24.055 24.097 24.14 24.182 24.225 24.267 24.31 24.353 24.395 24.438 24.48 580
590 24.48 24.523 24.565 24.608 24.65 24.693 24.735 24.778 24.82 24.863 24.905 590
600 24.905 24.948 24.99 25.033 25.075 25.118 25.16 25.203 25.245 25.288 25.33 600
610 25.33 25.373 25.415 25.458 25.5 25.543 25.585 25.627 25.67 25.712 25.755 610
620 25.755 25.797 25.84 25.882 25.924 25.967 26.009 26.052 26.094 26.136 26.179 620
630 26.179 26.221 26.263 26.306 26.348 26.39 26.433 26.475 26.517 26.56 26.602 630
640 26.602 26.644 26.687 26.729 26.771 26.814 26.856 26.898 26.94 26.983 27.025 640
650 27.025 27.067 27.109 27.152 27.194 27.236 27.278 27.32 27.363 27.405 27.447 650
660 27.447 27.489 27.531 27.574 27.616 27.658 27.7 27.742 27.784 27.826 27.869 660
670 27.869 27.911 27.953 27.995 28.037 28.079 28.121 28.163 28.205 28.247 28.289 670
680 28.289 28.332 28.374 28.416 28.458 28.5 28.542 28.584 28.626 28.668 28.71 680
690 28.71 28.752 28.794 28.835 28.877 28.919 28.961 29.003 29.045 29.087 29.129 690
700 29.129 29.171 29.213 29.255 29.297 29.338 29.38 29.422 29.464 29.506 29.548 700
710 29.548 29.589 29.631 29.673 29.715 29.757 29.798 29.84 29.882 29.924 29.965 710
720 29.965 30.007 30.049 30.09 30.132 30.174 30.216 30.257 30.299 30.341 30.382 720
730 30.382 30.424 30.466 30.507 30.549 30.59 30.632 30.674 30.715 30.757 30.798 730
740 30.798 30.84 30.881 30.923 30.964 31.006 31.047 31.089 31.13 31.172 31.213 740
750 31.213 31.255 31.296 31.338 31.379 31.421 31.462 31.504 31.545 31.586 31.628 750
760 31.628 31.669 31.71 31.752 31.793 31.834 31.876 31.917 31.958 32 32.041 760
770 32.041 32.082 32.124 32.165 32.206 32.247 32.289 32.33 32.371 32.412 32.453 770
780 32.453 32.495 32.536 32.577 32.618 32.659 32.7 32.742 32.783 32.824 32.865 780
790 32.865 32.906 32.947 32.988 33.029 33.07 33.111 33.152 33.193 33.234 33.275 790
˚C 0 1 2 3 4 5 6 7 8 9 10 ˚C
1100 45.119 45.157 45.194 45.232 45.27 45.308 45.346 45.383 45.421 45.459 45.497 1100
1110 45.497 45.534 45.572 45.61 45.647 45.685 45.723 45.76 45.798 45.836 45.873 1110
1120 45.873 45.911 45.948 45.986 46.024 46.061 46.099 46.136 46.174 46.211 46.249 1120
1130 46.249 46.286 46.324 46.361 46.398 46.436 46.473 46.511 46.548 46.585 46.623 1130
1140 46.623 46.66 46.697 46.735 46.772 46.809 46.847 46.884 46.921 46.958 46.995 1140
1150 46.995 47.033 47.07 47.107 47.144 47.181 47.218 47.256 47.293 47.33 47.367 1150
1160 47.367 47.404 47.441 47.478 47.515 47.552 47.589 47.626 47.663 47.7 47.737 1160
1170 47.737 47.774 47.811 47.848 47.884 47.921 47.958 47.995 48.032 48.069 48.105 1170
1180 48.105 48.142 48.179 48.216 48.252 48.289 48.326 48.363 48.399 48.436 48.473 1180
1190 48.473 48.509 48.546 48.582 48.619 48.656 48.692 48.729 48.765 48.802 48.838 1190
1200 48.838 48.875 48.911 48.948 48.984 49.021 49.057 49.093 49.13 49.166 49.202 1200
1210 49.202 49.239 49.275 49.311 49.348 49.384 49.42 49.456 49.493 49.529 49.565 1210
1220 49.565 49.601 49.637 49.674 49.71 49.746 49.782 49.818 49.854 49.89 49.926 1220
1230 49.926 49.962 49.998 50.034 50.07 50.106 50.142 50.178 50.214 50.25 50.286 1230
1240 50.286 50.322 50.358 50.393 50.429 50.465 50.501 50.537 50.572 50.608 50.644 1240
1250 50.644 50.68 50.715 50.751 50.787 50.822 50.858 50.894 50.929 50.965 51 1250
1260 51 51.036 51.071 51.107 51.142 51.178 51.213 51.249 51.284 51.32 51.355 1260
1270 51.355 51.391 51.426 51.461 51.497 51.532 51.567 51.603 51.638 51.673 51.708 1270
1280 51.708 51.744 51.779 51.814 51.849 51.885 51.92 51.955 51.99 52.025 52.06 1280
1290 52.06 52.095 52.13 52.165 52.2 52.235 52.27 52.305 52.34 52.375 52.41 1290
1300 52.41 52.445 52.48 52.515 52.55 52.585 52.62 52.654 52.689 52.724 52.759 1300
1310 52.759 52.794 52.828 52.863 52.898 52.932 52.967 53.002 53.037 53.071 53.106 1310
1320 53.106 53.14 53.175 53.21 53.244 53.279 53.313 53.348 53.382 53.417 53.451 1320
1330 53.451 53.486 53.52 53.555 53.589 53.623 53.658 53.692 53.727 53.761 53.795 1330
1340 53.795 53.83 53.864 53.898 53.932 53.967 54.001 54.035 54.069 54.104 54.138 1340
1350 54.138 54.172 54.206 54.24 54.274 54.308 54.343 54.377 54.411 54.445 54.479 1350
1360 54.479 54.513 54.547 54.581 54.615 54.649 54.683 54.717 54.751 54.785 54.819 1360
1370 54.819 54.852 54.886                 1370

˚C 0 1 2 3 4 5 6 7 8 9 10 ˚C
回到温度检测技术参考索引首页
