热电电压单位为毫伏
˚F -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 ˚F




450             -4.345 -4.345 -4.345 -4.344 -4.344 -450
-440 -4.344 -4.344 -4.343 -4.343 -4.342 -4.342 -4.341 -4.341 -4.34 -4.34 -4.339 -440
-430 -4.339 -4.338 -4.337 -4.337 -4.336 -4.335 -4.334 -4.333 -4.332 -4.331 -4.33 -430
-420 -4.33 -4.329 -4.327 -4.326 -4.325 -4.324 -4.322 -4.321 -4.319 -4.318 -4.316 -420
-410 -4.316 -4.315 -4.313 -4.312 -4.31 -4.308 -4.306 -4.305 -4.303 -4.301 -4.299 -410
-400 -4.299 -4.297 -4.295 -4.293 -4.291 -4.288 -4.286 -4.284 -4.282 -4.279 -4.277 -400
-390 -4.277 -4.275 -4.272 -4.27 -4.267 -4.264 -4.262 -4.259 -4.256 -4.254 -4.251 -390
-380 -4.251 -4.248 -4.245 -4.242 -4.239 -4.236 -4.233 -4.23 -4.226 -4.223 -4.22 -380
-370 -4.22 -4.217 -4.213 -4.21 -4.206 -4.203 -4.199 -4.196 -4.192 -4.189 -4.185 -370
-360 -4.185 -4.181 -4.177 -4.174 -4.17 -4.166 -4.162 -4.158 -4.154 -4.15 -4.145 -360
-350 -4.145 -4.141 -4.137 -4.133 -4.128 -4.124 -4.12 -4.115 -4.111 -4.106 -4.102 -350
-340 -4.102 -4.097 -4.092 -4.088 -4.083 -4.078 -4.073 -4.068 -4.064 -4.059 -4.054 -340
-330 -4.054 -4.049 -4.043 -4.038 -4.033 -4.028 -4.023 -4.017 -4.012 -4.007 -4.001 -330
-320 -4.001 -3.996 -3.99 -3.985 -3.979 -3.974 -3.968 -3.962 -3.957 -3.951 -3.945 -320
-310 -3.945 -3.939 -3.933 -3.927 -3.921 -3.915 -3.909 -3.903 -3.897 -3.891 -3.884 -310
-300 -3.884 -3.878 -3.872 -3.866 -3.859 -3.853 -3.846 -3.84 -3.833 -3.827 -3.82 -300
-290 -3.82 -3.813 -3.807 -3.8 -3.793 -3.786 -3.779 -3.773 -3.766 -3.759 -3.752 -290
-280 -3.752 -3.745 -3.738 -3.73 -3.723 -3.716 -3.709 -3.702 -3.694 -3.687 -3.679 -280
-270 -3.679 -3.672 -3.665 -3.657 -3.65 -3.642 -3.634 -3.627 -3.619 -3.611 -3.604 -270
-260 -3.604 -3.596 -3.588 -3.58 -3.572 -3.564 -3.556 -3.548 -3.54 -3.532 -3.524 -260
-250 -3.524 -3.516 -3.508 -3.499 -3.491 -3.483 -3.474 -3.466 -3.458 -3.449 -3.441 -250
-240 -3.441 -3.432 -3.424 -3.415 -3.407 -3.398 -3.389 -3.38 -3.372 -3.363 -3.354 -240
-230 -3.354 -3.345 -3.336 -3.327 -3.318 -3.309 -3.3 -3.291 -3.282 -3.273 -3.264 -230
-220 -3.264 -3.255 -3.246 -3.236 -3.227 -3.218 -3.208 -3.199 -3.189 -3.18 -3.171 -220
-210 -3.171 -3.161 -3.151 -3.142 -3.132 -3.123 -3.113 -3.103 -3.093 -3.084 -3.074 -210
-200 -3.074 -3.064 -3.054 -3.044 -3.034 -3.024 -3.014 -3.004 -2.994 -2.984 -2.974 -200
-190 -2.974 -2.964 -2.954 -2.943 -2.933 -2.923 -2.912 -2.902 -2.892 -2.881 -2.871 -190
-180 -2.871 -2.86 -2.85 -2.839 -2.829 -2.818 -2.808 -2.797 -2.786 -2.776 -2.765 -180
-170 -2.765 -2.754 -2.743 -2.733 -2.722 -2.711 -2.7 -2.689 -2.678 -2.667 -2.656 -170
-160 -2.656 -2.645 -2.634 -2.623 -2.612 -2.601 -2.589 -2.578 -2.567 -2.556 -2.544 -160
-150 -2.544 -2.533 -2.522 -2.51 -2.499 -2.488 -2.476 -2.465 -2.453 -2.442 -2.43 -150
-140 -2.43 -2.418 -2.407 -2.395 -2.384 -2.372 -2.36 -2.348 -2.337 -2.325 -2.313 -140
-130 -2.313 -2.301 -2.289 -2.277 -2.265 -2.254 -2.242 -2.23 -2.218 -2.206 -2.193 -130
-120 -2.193 -2.181 -2.169 -2.157 -2.145 -2.133 -2.121 -2.108 -2.096 -2.084 -2.072 -120
-110 -2.072 -2.059 -2.047 -2.035 -2.022 -2.01 -1.997 -1.985 -1.972 -1.96 -1.947 -110
-100 -1.947 -1.935 -1.922 -1.91 -1.897 -1.884 -1.872 -1.859 -1.846 -1.834 -1.821 -100
-90 -1.821 -1.808 -1.795 -1.783 -1.77 -1.757 -1.744 -1.731 -1.718 -1.705 -1.692 -90
-80 -1.692 -1.679 -1.666 -1.653 -1.64 -1.627 -1.614 -1.601 -1.588 -1.575 -1.562 -80
-70 -1.562 -1.549 -1.536 -1.522 -1.509 -1.496 -1.483 -1.47 -1.456 -1.443 -1.43 -70
-60 -1.43 -1.416 -1.403 -1.39 -1.376 -1.363 -1.349 -1.336 -1.323 -1.309 -1.296 -60
-50 -1.296 -1.282 -1.269 -1.255 -1.242 -1.228 -1.214 -1.201 -1.187 -1.174 -1.16 -50
-40 -1.16 -1.146 -1.133 -1.119 -1.105 -1.092 -1.078 -1.064 -1.05 -1.037 -1.023 -40
-30 -1.023 -1.009 -0.995 -0.981 -0.967 -0.954 -0.94 -0.926 -0.912 -0.898 -0.884 -30
-20 -0.884 -0.87 -0.856 -0.842 -0.828 -0.814 -0.8 -0.786 -0.772 -0.758 -0.744 -20
-10 -0.744 -0.73 -0.716 -0.702 -0.688 -0.674 -0.66 -0.646 -0.632 -0.617 -0.603 -10
0 -0.603 -0.589 -0.575 -0.561 -0.546 -0.532 -0.518 -0.504 -0.49 -0.475 -0.461 0
0 -0.461 -0.447 -0.433 -0.418 -0.404 -0.39 -0.375 -0.361 -0.347 -0.332 -0.318 0
10 -0.318 -0.304 -0.289 -0.275 -0.26 -0.246 -0.232 -0.217 -0.203 -0.188 -0.174 10
20 -0.174 -0.159 -0.145 -0.131 -0.116 -0.102 -0.087 -0.073 -0.058 -0.044 -0.029 20
30 -0.029 -0.015 0 0.014 0.029 0.043 0.058 0.072 0.087 0.101 0.116 30
40 0.116 0.13 0.145 0.159 0.174 0.188 0.203 0.217 0.232 0.246 0.261 40
50 0.261 0.275 0.29 0.305 0.319 0.334 0.349 0.363 0.378 0.393 0.407 50
60 0.407 0.422 0.437 0.451 0.466 0.481 0.496 0.51 0.525 0.54 0.555 60
70 0.555 0.57 0.584 0.599 0.614 0.629 0.644 0.659 0.674 0.688 0.703 70
80 0.703 0.718 0.733 0.748 0.763 0.778 0.793 0.808 0.823 0.838 0.853 80
90 0.853 0.868 0.883 0.898 0.913 0.928 0.943 0.958 0.974 0.989 1.004 90
˚F 0 1 2 3 4 5 6 7 8 9 10 ˚F
700 11.907 11.928 11.948 11.968 11.989 12.009 12.03 12.05 12.071 12.091 12.111 700
710 12.111 12.132 12.152 12.173 12.193 12.214 12.234 12.255 12.275 12.295 12.316 710
720 12.316 12.336 12.357 12.377 12.398 12.418 12.439 12.459 12.48 12.5 12.521 720
730 12.521 12.542 12.562 12.583 12.603 12.624 12.644 12.665 12.685 12.706 12.726 730
740 12.726 12.747 12.768 12.788 12.809 12.829 12.85 12.871 12.891 12.912 12.932 740
750 12.932 12.953 12.974 12.994 13.015 13.036 13.056 13.077 13.098 13.118 13.139 750
760 13.139 13.159 13.18 13.201 13.221 13.242 13.263 13.284 13.304 13.325 13.346 760
770 13.346 13.366 13.387 13.408 13.428 13.449 13.47 13.491 13.511 13.532 13.553 770
780 13.553 13.574 13.594 13.615 13.636 13.657 13.677 13.698 13.719 13.74 13.76 780
790 13.76 13.781 13.802 13.823 13.844 13.864 13.885 13.906 13.927 13.948 13.969 790
800 13.969 13.989 14.01 14.031 14.052 14.073 14.094 14.114 14.135 14.156 14.177 800
810 14.177 14.198 14.219 14.24 14.26 14.281 14.302 14.323 14.344 14.365 14.386 810
820 14.386 14.407 14.428 14.448 14.469 14.49 14.511 14.532 14.553 14.574 14.595 820
830 14.595 14.616 14.637 14.658 14.679 14.7 14.721 14.742 14.763 14.784 14.804 830
840 14.804 14.825 14.846 14.867 14.888 14.909 14.93 14.951 14.972 14.993 15.014 840
850 15.014 15.035 15.056 15.077 15.098 15.119 15.14 15.162 15.183 15.204 15.225 850
860 15.225 15.246 15.267 15.288 15.309 15.33 15.351 15.372 15.393 15.414 15.435 860
870 15.435 15.456 15.477 15.498 15.52 15.541 15.562 15.583 15.604 15.625 15.646 870
880 15.646 15.667 15.688 15.709 15.731 15.752 15.773 15.794 15.815 15.836 15.857 880
890 15.857 15.878 15.9 15.921 15.942 15.963 15.984 16.005 16.027 16.048 16.069 890
900 16.069 16.09 16.111 16.132 16.154 16.175 16.196 16.217 16.238 16.26 16.281 900
910 16.281 16.302 16.323 16.344 16.366 16.387 16.408 16.429 16.45 16.472 16.493 910
920 16.493 16.514 16.535 16.557 16.578 16.599 16.62 16.642 16.663 16.684 16.705 920
930 16.705 16.727 16.748 16.769 16.79 16.812 16.833 16.854 16.875 16.897 16.918 930
940 16.918 16.939 16.961 16.982 17.003 17.025 17.046 17.067 17.088 17.11 17.131 940
950 17.131 17.152 17.174 17.195 17.216 17.238 17.259 17.28 17.302 17.323 17.344 950
960 17.344 17.366 17.387 17.408 17.43 17.451 17.472 17.494 17.515 17.536 17.558 960
970 17.558 17.579 17.601 17.622 17.643 17.665 17.686 17.707 17.729 17.75 17.772 970
980 17.772 17.793 17.814 17.836 17.857 17.879 17.9 17.921 17.943 17.964 17.986 980
990 17.986 18.007 18.028 18.05 18.071 18.093 18.114 18.136 18.157 18.178 18.2 990
1000 18.2 18.221 18.243 18.264 18.286 18.307 18.328 18.35 18.371 18.393 18.414 1000
1010 18.414 18.436 18.457 18.479 18.5 18.522 18.543 18.565 18.586 18.608 18.629 1010
1020 18.629 18.65 18.672 18.693 18.715 18.736 18.758 18.779 18.801 18.822 18.844 1020
1030 18.844 18.865 18.887 18.908 18.93 18.951 18.973 18.994 19.016 19.037 19.059 1030
1040 19.059 19.081 19.102 19.124 19.145 19.167 19.188 19.21 19.231 19.253 19.274 1040
1050 19.274 19.296 19.317 19.339 19.36 19.382 19.404 19.425 19.447 19.468 19.49 1060
1060 19.49 19.511 19.533 19.554 19.576 19.598 19.619 19.641 19.662 19.684 19.705 1060
1070 19.705 19.727 19.749 19.77 19.792 19.813 19.835 19.857 19.878 19.9 19.921 1070
1080 19.921 19.943 19.964 19.986 20.008 20.029 20.051 20.072 20.094 20.116 20.137 1060
1090 20.137 20.159 20.181 20.202 20.224 20.245 20.267 20.289 20.31 20.332 20.353 1090
1100 20.353 20.375 20.397 20.418 20.44 20.462 20.483 20.505 20.527 20.548 20.57 1100
1110 20.57 20.591 20.613 20.635 20.656 20.678 20.7 20.721 20.743 20.765 20.786 1110
1120 20.786 20.808 20.83 20.851 20.873 20.895 20.916 20.938 20.96 20.981 21.003 1120
1130 21.003 21.025 21.046 21.068 21.09 21.111 21.133 21.155 21.176 21.198 21.22 1130
1140 21.22 21.241 21.263 21.285 21.306 21.328 21.35 21.371 21.393 21.415 21.437 1140
1150 21.437 21.458 21.48 21.502 21.523 21.545 21.567 21.588 21.61 21.632 21.654 1150
1160 21.654 21.675 21.697 21.719 21.74 21.762 21.784 21.806 21.827 21.849 21.871 1160
1170 21.871 21.892 21.914 21.936 21.958 21.979 22.001 22.023 22.044 22.066 22.088 1170
1180 22.088 22.11 22.131 22.153 22.175 22.197 22.218 22.24 22.262 22.284 22.305 1180
1190 22.305 22.327 22.349 22.37 22.392 22.414 22.436 22.457 22.479 22.501 22.523 1190
1200 22.523 22.544 22.566 22.588 22.61 22.631 22.653 22.675 22.697 22.718 22.74 1200
1210 22.74 22.762 22.784 22.805 22.827 22.849 22.871 22.893 22.914 22.936 22.958 1210
1220 22.958 22.98 23.001 23.023 23.045 23.067 23.088 23.11 23.132 23.154 23.178 1220
1230 23.176 23.197 23.219 23.241 23.263 23.284 23.306 23.328 23.35 23.372 23.393 1230
1240 23.393 23.415 23.437 23.459 23.48 23.502 23.524 23.546 23.568 23.589 23.611 1240
1250 23.611 23.633 23.655 23.676 23.698 23.72 23.742 23.764 23.785 23.807 23.829 1250
1260 23.829 23.851 23.873 23.894 23.916 23.938 23.96 23.982 24.003 24.025 24.047 1260
1270 24.047 24.069 24.091 24.112 24.134 24.156 24.178 24.2 24.221 24.243 24.265 1270
1280 24.265 24.287 24.309 24.33 24.352 24.374 24.396 24.418 24.439 24.461 24.483 1280
1290 24.483 24.505 24.527 24.548 24.57 24.592 24.614 24.636 24.658 24.679 24.701 1290
˚F 0 1 2 3 4 5 6 7 8 9 10 ˚F
1900 37.71 37.731 37.753 37.774 37.795 37.817 37.838 37.859 37.881 37.902 37.923 1900
1910 37.923 37.945 37.966 37.987 38.009 38.03 38.051 38.073 38.094 38.115 38.136 1910
1920 38.136 38.158 38.179 38.2 38.222 38.243 38.264 38.285 38.307 38.328 38.349 1920
1930 38.349 38.37 38.392 38.413 38.434 38.456 38.477 38.498 38.519 38.541 38.562 1930
1940 38.562 38.583 38.604 38.626 38.647 38.668 38.689 38.711 38.732 38.753 38.774 1940
1950 38.774 38.795 38.817 38.838 38.859 38.88 38.902 38.923 38.944 38.965 38.986 1950
1960 38.986 39.008 38.029 39.05 39.071 39.093 39.114 39.135 39.156 39.177 39.198 1960
1970 39.198 39.22 39.241 39.262 39.283 39.304 39.326 39.347 39.368 39.389 39.41 1970
1980 39.41 39.431 39.453 39.474 39.495 39.516 39.537 39.558 39.58 39.601 39.622 1980
1990 39.622 39.643 39.664 39.685 39.706 39.728 39.749 39.77 39.791 39.812 39.833 1990
2000 39.833 39.854 39.875 39.897 39.918 39.939 39.96 39.981 40.002 40.023 40.044 2000
2010 40.044 40.066 40.087 40.108 40.129 40.15 40.171 40.192 40.213 40.234 40.255 2010
2020 40.255 40.276 40.297 40.319 40.34 40.361 40.382 40.403 40.424 40.445 40.466 2020
2030 40.466 40.487 40.508 40.529 40.55 40.571 40.592 40.613 40.634 40.655 40.677 2030
2040 40.677 40.698 40.719 40.74 40.761 40.782 40.803 40.824 40.845 40.866 40.887 2040
2050 40.887 40.908 40.929 40.950 40.971 40.992 41.013 41.034 41.055 41.076 41.097 2050
2060 41.097 41.118 41.139 41.16 41.181 41.202 41.223 41.244 41.265 41.286 41.307 2060
2070 41.307 41.328 41.349 41.37 41.39 41.411 41.432 41.453 41.474 41.495 41.516 2070
2080 41.516 41.537 41.558 41.579 41.6 41.621 41.642 41.663 41.684 41.705 41.725 2080
2090 41.725 41.746 41.767 41.788 41.809 41.83 41.851 41.872 41.893 41.914 41.935 2090
2100 41.935 41.955 41.976 41.997 42.018 42.039 42.06 42.081 42.102 42.123 42.143 2100
2110 42.143 42.164 42.185 42.206 42.227 42.248 42.269 42.289 42.31 42.331 42.352 2110
2120 42.352 42.373 42.394 42.415 42.435 42.456 42.477 42.498 42.519 42.54 42.56 2120
2130 42.56 42.581 42.602 42.623 42.644 42.664 42.685 42.706 42.727 42.748 42.768 2130
2140 42.768 42.789 42.81 42.831 42.852 42.872 42.893 42.914 42.935 42.956 42.976 2140
˚F 0 1 2 3 4 5 6 7 8 9 10 ˚F
˚F 0 1 2 3 4 5 6 7 8 9 10 ˚F
100 1.004 1.019 1.034 1.049 1.065 1.08 1.095 1.11 1.125 1.141 1.156 100
110 1.156 1.171 1.186 1.202 1.217 1.232 1.248 1.263 1.278 1.294 1.309 110
120 1.309 1.324 1.34 1.355 1.371 1.386 1.402 1.417 1.432 1.448 1.463 120
130 1.463 1.479 1.494 1.51 1.525 1.541 1.557 1.572 1.588 1.603 1.619 130
140 1.619 1.635 1.65 1.666 1.682 1.697 1.713 1.729 1.744 1.76 1.776 140
150 1.776 1.791 1.807 1.823 1.839 1.855 1.87 1.886 1.902 1.918 1.934 150
160 1.934 1.95 1.965 1.981 1.997 2.013 2.029 2.045 2.061 2.077 2.093 160
170 2.093 2.109 2.125 2.141 2.157 2.173 2.189 2.205 2.221 2.237 2.253 170
180 2.253 2.269 2.285 2.301 2.318 2.334 2.35 2.366 2.382 2.398 2.415 180
190 2.415 2.431 2.447 2.463 2.48 2.496 2.512 2.528 2.545 2.561 2.577 190
200 2.577 2.594 2.61 2.626 2.643 2.659 2.676 2.692 2.708 2.725 2.741 200
210 2.741 2.758 2.774 2.791 2.807 2.824 2.84 2.857 2.873 2.89 2.906 210
220 2.906 2.923 2.939 2.956 2.973 2.989 3.006 3.022 3.039 3.056 3.072 220
230 3.072 3.089 3.106 3.123 3.139 3.156 3.173 3.189 3.206 3.223 3.24 230
240 3.24 3.257 3.273 3.29 3.307 3.324 3.341 3.358 3.374 3.391 3.408 240
250 3.408 3.425 3.442 3.459 3.476 3.493 3.51 3.527 3.544 3.561 3.578 250
260 3.578 3.595 3.612 3.629 3.646 3.663 3.68 3.697 3.714 3.731 3.748 260
270 3.748 3.766 3.783 3.8 3.817 3.834 3.851 3.869 3.886 3.903 3.92 270
280 3.92 3.937 3.955 3.972 3.989 4.007 4.024 4.041 4.058 4.076 4.093 280
290 4.093 4.11 4.128 4.145 4.162 4.18 4.197 4.215 4.232 4.25 4.267 290
300 4.267 4.284 4.302 4.319 4.337 4.354 4.372 4.389 4.407 4.424 4.442 300
310 4.442 4.459 4.477 4.495 4.512 4.53 4.547 4.565 4.583 4.6 4.618 310
320 4.618 4.635 4.653 4.671 4.688 4.706 4.724 4.742 4.759 4.777 4.795 320
330 4.795 4.813 4.83 4.848 4.866 4.884 4.901 4.919 4.937 4.955 4.973 330
340 4.973 4.991 5.008 5.026 5.044 5.062 5.08 5.098 5.116 5.134 5.152 340
350 5.152 5.17 5.188 5.206 5.224 5.241 5.259 5.277 5.295 5.314 5.332 350
360 5.332 5.35 5.368 5.386 5.404 5.422 5.44 5.458 5.476 5.494 5.512 360
370 5.512 5.531 5.549 5.567 5.585 5.603 5.621 5.639 5.658 5.676 5.694 370
380 5.694 5.712 5.731 5.749 5.767 5.785 5.804 5.822 5.84 5.858 5.877 380
390 5.877 5.895 5.913 5.932 5.95 5.968 5.987 6.005 6.024 6.042 6.06 390
400 6.06 6.079 6.097 6.116 6.134 6.152 6.171 6.189 6.208 6.226 6.245 400
410 6.245 6.263 6.282 6.3 6.319 6.337 6.356 6.374 6.393 6.411 6.43 410
420 6.43 6.449 6.467 6.486 6.504 6.523 6.542 6.56 6.579 6.597 6.616 420
430 6.616 6.635 6.653 6.672 6.691 6.71 6.728 6.747 6.766 6.784 6.803 430
440 6.803 6.822 6.841 6.859 6.878 6.897 6.916 6.934 6.953 6.972 6.991 440
450 6.991 7.01 7.029 7.047 7.066 7.085 7.104 7.123 7.142 7.161 7.179 450
460 7.179 7.198 7.217 7.236 7.255 7.274 7.293 7.312 7.331 7.35 7.369 460
470 7.369 7.388 7.407 7.426 7.445 7.464 7.483 7.502 7.521 7.54 7.559 470
480 7.559 7.578 7.597 7.616 7.635 7.654 7.673 7.692 7.711 7.731 7.75 480
490 7.75 7.769 7.788 7.807 7.826 7.845 7.865 7.884 7.903 7.922 7.941 490
500 7.941 7.96 7.98 7.999 8.018 8.037 8.057 8.076 8.095 8.114 8.134 500
510 8.134 8.153 8.172 8.191 8.211 8.23 8.249 8.269 8.288 8.307 8.327 510
520 8.327 8.346 8.365 8.385 8.404 8.423 8.443 8.462 8.482 8.501 8.52 520
530 8.52 8.54 8.559 8.579 8.598 8.617 8.637 8.656 8.676 8.695 8.715 530
540 8.715 8.734 8.754 8.773 8.793 8.812 8.832 8.851 8.871 8.89 8.91 540
550 8.91 8.929 8.949 8.968 8.988 9.008 9.027 9.047 9.066 9.086 9.105 550
560 9.105 9.125 9.145 9.164 9.184 9.204 9.223 9.243 9.262 9.282 9.302 560
570 9.302 9.321 9.341 9.361 9.381 9.4 9.42 9.44 9.459 9.479 9.499 570
580 9.499 9.519 9.538 9.558 9.578 9.598 9.617 9.637 9.657 9.677 9.696 580
590 9.696 9.716 9.736 9.756 9.776 9.795 9.815 9.835 9.855 9.875 9.895 590
600 9.895 9.914 9.934 9.954 9.974 9.994 10.014 10.034 10.054 10.073 10.093 600
610 10.093 10.113 10.133 10.153 10.173 10.193 10.213 10.233 10.253 10.273 10.293 610
620 10.293 10.313 10.333 10.353 10.373 10.393 10.413 10.433 10.453 10.473 10.493 620
630 10.493 10.513 10.533 10.553 10.573 10.593 10.613 10.633 10.653 10.673 10.693 630
640 10.693 10.713 10.733 10.753 10.774 10.794 10.814 10.834 10.854 10.874 10.894 640
650 10.894 10.914 10.934 10.955 10.975 10.995 11.015 11.035 11.055 11.076 11.096 650
660 11.096 11.116 11.136 11.156 11.177 11.197 11.217 11.237 11.257 11.278 11.298 660
670 11.298 11.318 11.338 11.359 11.379 11.399 11.419 11.44 11.46 11.48 11.501 670
680 11.501 11.521 11.541 11.561 11.582 11.602 11.622 11.643 11.663 11.683 11.704 680
690 11.704 11.724 11.744 11.765 11.785 11.805 11.826 11.846 11.867 11.887 11.907 690
˚F 0 1 2 3 4 5 6 7 8 9 10 ˚F
1300 24.701 24.723 24.745 24.767 24.788 24.81 24.832 24.854 24.876 24.897 24.919 1300
1310 24.919 24.941 24.963 24.985 25.007 25.028 25.05 25.072 25.094 25.116 25.137 1310
1320 25.137 25.159 25.181 25.203 25.225 25.247 25.268 25.29 25.312 25.334 25.356 1320
1330 25.356 25.377 25.399 25.421 25.443 25.465 25.487 25.508 25.53 25.552 25.574 1330
1340 25.574 25.596 25.618 25.639 25.661 25.683 25.705 25.727 25.748 25.77 25.792 1340
1350 25.792 25.814 25.836 25.858 25.879 25.901 25.923 25.945 25.967 25.989 26.01 1350
1360 26.01 26.032 26.054 26.076 26.098 26.119 26.141 26.163 26.185 26.207 26.229 1360
1370 26.229 26.25 26.272 26.294 26.316 26.338 26.36 26.381 26.403 26.425 26.447 1370
1380 26.447 26.469 26.491 26.512 26.534 26.556 26.578 26.6 26.622 26.643 26.665 1380
1390 26.665 26.687 26.709 26.731 26.752 26.774 26.796 26.818 26.84 26.862 26.883 1390
1400 26.883 26.905 26.927 26.949 26.971 26.993 27.014 27.036 27.058 27.08 27.102 1400
1410 27.102 27.124 27.145 27.167 27.189 27.211 27.233 27.254 27.276 27.298 27.32 1410
1420 27.32 27.342 27.364 27.385 27.407 27.429 27.451 27.473 27.495 27.516 27.538 1420
1430 27.538 27.56 27.582 27.604 27.625 27.647 27.669 27.691 27.713 27.735 27.756 1430
1440 27.756 27.778 27.8 27.822 27.844 27.866 27.887 27.909 27.931 27.953 27.975 1440
1450 27.975 27.996 28.018 28.04 28.062 28.084 28.105 28.127 28.149 28.171 28.193 1450
1460 28.193 28.215 28.236 28.258 28.28 28.302 28.324 28.345 28.367 28.389 28.411 1460
1470 28.411 28.433 28.455 28.476 28.498 28.52 28.542 28.564 28.585 28.607 28.629 1470
1480 28.629 28.651 28.673 28.694 28.716 28.738 28.76 28.782 28.803 28.825 28.847 1480
1490 28.847 28.869 28.891 28.912 28.934 28.956 28.978 29 29.021 29.043 29.065 1490
1500 29.085 29.087 29.109 29.13 29.152 29.174 29.196 29.218 29.239 29.261 29.283 1500
1510 29.283 29.305 29.327 29.348 29.37 29.392 29.414 29.436 29.457 29.479 29.501 1510
1520 29.501 29.523 29.545 29.566 29.588 29.61 29.632 29.653 29.675 29.697 29.719 I520
1530 29.719 29.741 29.762 29.784 29.806 29.828 29.85 29.871 29.893 29.915 29.937 I530
1540 29.937 29.958 29.98 30.002 30.024 30.046 30.067 30.089 30.111 30.133 30.154 IS40
1550 30.154 30.176 30.198 30.22 30.242 30.263 30.285 30.307 30.329 30.35 30.372 1550
1560 30.372 30.304 30.416 30.437 30.459 30.481 30.503 30.524 30.546 30.568 30.59 1560
1570 30.59 30.611 30.633 30.655 30.677 30.699 30.72 30.742 30.764 30.786 30.807 1570
1580 30.807 30.829 30.851 30.873 30.894 30.916 30.938 30.96 30.981 31.003 31.025 1580
1590 31.025 31.047 31.068 31.09 31.112 31.133 31.155 31.177 31.199 31.22 31.242 1590
1600 31.242 31.264 31.286 31.307 31.329 31.351 31.373 31.394 31.416 31.438 31.459 1600
1610 31.45 31.481 31.503 31.525 31.546 31.568 31.59 31.612 31.633 31.655 31.677 1610
1620 31.677 31.698 31.72 31.742 31.764 31.785 31.807 31.829 31.85 31.872 31.894 1620
1630 31.894 31.916 31.937 31.959 31.981 32.002 32.024 32.046 32.068 32.089 32.111 1630
1640 32.111 32.133 32.154 32.176 32.198 32.219 32.241 32.263 32.284 32.306 32.328 1640
1650 32.328 32.35 32.371 32.393 32.415 32.436 32.458 32.48 32.501 32.523 32.545 1650
1660 32.545 32.566 32.588 32.61 32.631 32.653 32.675 32.696 32.718 32.74 32.761 1660
1670 32.716 32.783 32.805 32.826 32.848 32.87 32.891 32.913 32.935 32.956 32.978 1670
1680 32.978 32 32.021 32.043 33.065 35.086 33.108 33.13 33.151 33.173 33.195 1680
1690 33.195 33.216 33.238 33.26 33.281 33.303 33.325 33.346 33.368 33.389 33.411 1690
1700 33.411 33.433 33.454 33.476 33.498 33.519 33.541 33.563 33.584 33.606 33.627 1700
1710 33.627 33.649 33.671 33.692 33.714 33.736 33.757 33.779 33.8 33.822 33.844 1710
1720 33.844 33.865 33.887 33.908 33.93 33.952 33.973 33.995 34.016 34.038 34.06 1720
1730 34.06 34.081 34.103 34.124 34.146 34.168 34.189 34.211 34.232 34.254 34.276 1730
1740 34.276 34.297 34.319 34.34 34.362 34.384 34.405 34.427 34.448 34.47 34.491 1740
1750 34.491 34.513 34.535 34.556 34.578 34.599 34.621 34.642 34.664 34.686 34.707 1750
1760 34.707 34.729 34.75 34.772 34.793 34.815 34.836 34.858 34.879 34.901 34.923 1760
1770 34.923 34.944 34.966 34.987 35.009 35.03 35.052 35.073 35.095 35.116 35.138 1770
1790 35.138 35.16 35.181 35.203 35.224 35.246 35.267 35.289 35.31 35.332 35.353 1780
1790 35.353 35.375 35.396 35.418 35.439 35.461 35.482 35.504 35.525 35.547 35.568 1790
1800 35.568 35.59 35.611 35.633 35.654 35.676 35.697 35.719 35.74 35.762 35.783 1800
1810 35.783 35.805 35.826 35.848 35.869 35.891 35.912 35.934 35.955 35.977 35.998 1810
1820 35.998 35.019 36.041 36.062 36.084 36.105 36.127 36.148 36.17 36.191 36.213 1820
1830 35.213 35.234 36.256 36.277 36.298 36.32 36.341 36.363 36.384 36.406 36.427 1830
1840 36.427 36.449 36.47 36.491 36.513 36.534 36.556 36.577 36.599 36.62 36.641 1840
1850 36.841 36.663 36.684 36.706 36.727 36.748 36.77 36.791 38.813 36.834 36.855 1850
1860 36.855 36.877 36.898 36.92 36.941 36.962 36.984 37.005 37.027 37.048 37.069 1860
1870 37.069 37.091 37.112 37.134 37.155 37.176 37.198 37.219 37.24 37.262 37.283 1870
1880 37.283 37.305 37.326 37.347 37.369 37.39 37.411 37.433 37.454 37.475 37.497 1880
1890 37.497 37.518 37.539 37.561 37.582 37.603 37.625 37.646 37.667 37.689 37.71 1890
˚F 0 1 2 3 4 5 6 7 8 9 10 ˚F
2150 42.976 42.997 43.018 43.039 43.059 43.08 43.101 43.122 43.142 43.163 43.184 2150
2160 43.184 43.205 43.225 43.246 43.267 43.288 43.308 43.329 43.35 43.37 43.391 2160
2170 43.391 43.412 43.433 43.453 43.474 43.495 43.515 43.536 43.557 43.578 43.598 2170
2180 43.598 43.619 43.64 43.66 43.681 43.702 43.722 43.743 43.764 43.784 43.805 2180
2190 43.805 43.826 43.846 43.867 43.888 43.908 43.929 43.95 43.97 43.991 43.012 2190
2200 44.012 44.032 44.053 44.073 44.094 44.115 44.135 44.156 44.177 44.197 44.218 2200
2210 44.218 44.238 44.259 44.28 44.3 44.321 44.341 44.362 44.383 44.403 44.424 2210
2220 44.424 44.444 44.465 44.485 44.506 44.527 44.547 44.568 44.588 44.609 44.629 2220
2230 44.629 44.65 44.671 44.691 44.712 44.732 44.753 44.773 44.794 44.814 44.835 2230
2240 44.835 44.855 44.876 44.896 44.917 44.937 44.958 44.978 44.999 45.019 45.04 2240
2250 45.04 45.06 45.081 45.101 45.122 45.142 45.163 45.183 45.204 45.224 45.245 2250
2260 45.245 45.265 45.286 45.306 45.326 45.347 45.367 45.388 45.408 45.429 45.449 2260
2270 45.449 45.469 45.49 45.51 45.531 45.551 45.572 45.592 45.612 45.633 45.653 2270
2280 45.653 45.674 45.694 45.714 45.735 45.755 45.775 45.796 45.816 45.837 45.857 2280
2290 45.857 45.877 45.898 45.918 45.938 45.959 45.979 45.999 46.02 46.04 46.06 2290
2300 46.06 46.081 46.101 46.121 46.142 46.162 46.182 46.202 46.223 46.243 46.263 2300
2310 46.263 46.284 46.304 46.324 46.344 46.365 46.385 46.405 46.425 46.446 46.466 2310
2320 46.466 46.486 46.506 46.527 46.547 46.567 48.587 46.608 46.628 46.648 46.668 2320
2330 46.668 46.688 46.709 46.729 46.749 46.769 48.789 46.81 48.83 46.85 46.87 2330
2340 48.87 46.89 46.91 48.931 46.951 46.971 48.991 47.011 47-031 47.051 47.071 2340
2350 47.071 47.092 47.112 47.132 47.152 47.172 47.192 47.212 47.232 47.252 47.272 2350
2360 47.272 47.292 47.312 47.333 47.353 47.373 47.393 47.413 47.433 47.453 47.473 2360
2370 47.473 47.493 47.513                 2370


˚F 0 1 2 3 4 5 6 7 8 9 10 ˚F
回到温度检测技术参考索引首页
