Flange Trough Collar Around All Sides of Door Opening
Interior Print Pocket
Oil-Resistant Gasket
Ground Stud On Door
12" Removable Floor Stands
Hasp and Staple for Padlocking
Removable Center Post
Panel Supports
Heavy Duty Lifting Eyes
Stainless Steel Clamps On 3 Sides of Door
No Door Stiffener Required
Collar Studs Provided for Mounting Optional Sub-Panels
产品描述
Application
The SCE-HSSLP Series electrical enclosure is designed to house
electrical equipment in damp and wet areas, corrosive atmospheres
and for outdoor applications. For outdoor
application a drip shield is recommended.
by Saginaw Control Finish
#4 brushed finish on all exterior surfaces.
Optional panels are powder coated white.
Industry Standards
NEMA Type 4, 4X, 12 & 13
UL Listed Type 4, 4X & 12
CSA Type 4, 4X & 12
IEC 60529 IP 66
