Lightweight Oil Immersion Heater with Integral Thermostat—2" NPT Steel Fitting |
| ARMTO-2 Series |
|
 |
|
|
|
|
|
¥
14,320.00
ARMTO-2155/120V
|
| • |
Built-In Thermostat— Three Temperature Ranges Available
|
| • |
1.5 to 6 KW
|
| • |
120, 208 240 or 480 V, 1 Phase
|
| • |
Rugged, 2 Element Design
|
| • |
Premium Grade Steel Sheath
|
| • |
Lower Watt Densities for Heating Lightweight Oils
|
View related products - Immersion Heaters
|
| |
|
|
|
 |
Please Note: The integral thermostat functions as a temperature control only. This is not a fail safe device. An
approved pressure and/or temperature limit control should be used with these heaters to assure safe operation. See
the Temperature section for our selection of control devices.
| kW |
W/in2 |
No. Htg.
Elem. |
Dim.B
in(cm) |
†Temp.Range 200-550°F
Model No. |
Temp.Range 60-250°F
Model No. |
Temp.Range 0-100°F
Model No. |
| ARMTO- 2 Series with General Purpose Enclosure |
| 1.5 | 24 | 2 | 11¾ (30) | ARMTO-2155/* | ARMTO-2155T2/* | ARMTO-2155T1/* |
| 2 | 24 | 2 | 17¾ (45) | ARMTO-2205/* | ARMTO-2205T2/* | ARMTO-2205T1/* |
| 2.5 | 26 | 2 | 19 5/8 (50) | ARMTO-2255/* | ARMTO-2255T2/* | ARMTO-2255T1/* |
| 3 | 23 | 2 | 24 7/8 (63) | ARMTO-2305/* | ARMTO-2305T2/* | ARMTO-2305T1/* |
| 4 | 23 | 2 | 32¾ (83) | ARMTO-2405/* | ARMTO-2405T2/* | ARMTO-2405T1/* |
| 5 | 23 | 2 | 40¼ (102) | ARMTO-2505/* | ARMTO-2505T2/* | ARMTO-2505T1/* |
| 6 | 23 | 2 | 47¾ (121) | ARMTO-2605/** | ARMTO-2605T2/** | ARMTO-2605T1/** |
| ARMTO-2 Series with Moisture Resistant/Explosion Resistant Enclosure |
| 1.5 | 24 | 2 | 1¾ (30) | ARMTO-2155E2/* | ARMTO-2155E2T2/* | ARMTO-2155E2T1/* |
| 2 | 24 | 2 | 17¾ (45) | ARMTO-2205E2/* | ARMTO-2205E2T2/* | ARMTO-2205E2T1/* |
| 2.5 | 26 | 2 | 19 5/8 (50) | ARMTO-2255E2/* | ARMTO-2255E2T2/* | ARMTO-2255E2T1/* |
| 3 | 23 | 2 | 24 7/8 (63) | ARMTO-2305E2/* | ARMTO-2305E2T2/* | ARMTO-2305E2T1/* |
| 4 | 23 | 2 | 32¾ (83) | ARMTO-2405E2/* | ARMTO-2405E2T2/* | ARMTO-2405E2T1/* |
| 5 | 23 | 2 | 40¼ (102) | ARMTO-2505E2/* | ARMTO-2505E2T2/* | ARMTO-2505E2T1/* |
| 6 | 23 | 2 | 47¾ (121) | ARMTO-2605E2/** | ARMTO-2605E2T2/** | ARMTO-2605E2T1/** |
/*Designate voltage, i.e., insert 120 for 120 Vac, 208 for 208 Vac, 240 for 240 Vac, or 480 for 480 Vac.
/** Designate voltage, ie., insert 208 for 208 Vac, 240 for 240 Vac, or 480 for 480 Vac.
†Heaters with Temperature Ranges 200-550°F are not UL listed.
Caution: Explosion resistant type E2 construction refers to heater design features which provide explosion resisting containment of electrical
wiring according to National Electric Code. Abnormal application or use of heaters which results in excessive temperatures can create
hazardous conditions which can lead to fire
Consult Section Z for data on allowable watt densities for more viscous materials.
|
|
|
|
|
|
† Price are shown in RMB.
|
|
|
|
|
|
|
|
|
Part Number Builder |
|
|
|
|
|
|
|
|
Option Descriptions
|
|
(1)
|
Wattage
|
| |
Select
155 for 1.5 kW
205 for 2 kW
255 for 2.5 kW
305 for 3 kW
405 for 4 kW
505 for 5 kW
605 for 6 kW
|
(2)
|
Temperature Range and Enclosure Style
|
| |
Select
Nothing(leave field blank) for 200-550°F with a general purpose terminal enclosure
T1 for 0-100°F with a general purpose terminal enclosure
T2 for 60-250°F with a general purpose terminal enclosure
E2 for 200-550°F with a moisture resistant/explosion resistant enclosure
E2T1 for 0-100°F with a moisture resistant/explosion resistant enclosure
E2T2 for 60-250°F with a moisture resistant/explosion resistant enclosure
|
(3)
|
Voltage
|
| |
Select
120V for 120 Vac
208V for 208 Vac
240V for 240 Vac
480V for 480 Vac
|
|
NOTE: All combinations may not be valid, check spec sheet for valid part numbers.
|
| |
|
|
|
|
|
|
| |
|
