SPECIFICATIONS Heating Element: High performance cartridge heater Heat Sink: Extruded aluminum profile Overheat Protection: Built-in temperature limiter Axial Fan (Ball Bearing): Service life 50,000h @ 25°C (77°F) Air Flow, Free Blowing: 160 m2/h (94 cfm) Connection: 2-pole terminal AWG 16 max (1.5 mm²) with strain relief, clamping torque 0.8 Nm max Mounting: CR030: M5 screws (not included) CR130: Clip for 35 mm DIN rail, EN 60 715 or M6 screws (not included) Position: Preferably horizontal Wiring Compartment: Plastic, UL94V-0, black Dimensions: CR030: 168 x 145 x 99 mm (6.6 x 5.7 x 3.9") CR130: 182 x 160 x 99 mm (7.2 x 6.3 x 3.9") Weight: 1.4 kg (3.1 lb) Operating Temperature: -45 to 70°C (-49 to 158°F) Storage Temperature: -45 to 70°C (-49 to 158°F) Protection Class: II (double isolated) Protection Type: NEMA 2 (IP20)
