APPLICATIONS
Used to heat clean and corrosive solutions. Ideal for side-arm heating,
in-line circulation and engine pre-heaters.
FEATURES
Terminal Enclosure — E1 General Purpose is standard. Elements — INCOLOY sheath elements rated 75 W/In2. Flange — Stainless steel flange for corrosion resistance. Vessel — CPVC pipe body material is resistant to many corrosive
solutions and is ideal for water applications. Pipe body material
provides good thermal insulation, reducing heat loss. Thermostat — Integral thermostat with 60 to 190°F temperature
range, located inside the terminal enclosure. High Limit Control — Integral automatic cutout (overtemperature
control) protects against fluid or element overheat (set to open
at 195°F). Vibration Resistant — Vibration resistant construction to withstand
vibrations typically experienced on many types of operating equipment
(i.e., engines). Easy to Install — Minimal size and light weight, no supporting brackets
are required.
