Terminal Enclosures: Four types of terminal enclosures are available based on application needs. The standard stock heater enclosure is designated ( -E1). This is a general purpose enclosure used for many applications. Moisture resistant/explosion resistant (-E2); explosion resistant (-E3) or moisture Resistant (-E4) enclosures are available .
Elements: Sturdy 0.475" diameter incoloy sheathed elements provide superior strength and stability. OMEGALUX elements utilize high quality resistance heating wire for coil construction. The coil is surrounded with high purity magnesium oxide which is compacted to a dense solid to ensure high thermal conductivity and dielectric strength.
APPLICATIONS:
Pure Water and Mildly Corrosive Solutions: These systems are ideal for heating of di-ionized water that is highly aggressive to mild steel and for heating mildly corrosive solutions (pH5 to pH9)
kW
Volts
Phase
Dimensions (In.)
Model No.
Wt. (Lbs.)
A
B
C
Series 03 — 3 inch, 150 lb 304 passivated stainless steel vessel, 3 INCOLOY elements
(45 W/In2) with side mounted thermostat (60 to 250°F) — 1" NPT pipe inlet and outlet
6
240
1-3
32 15/16
22 1/2
16 1/2
NWHIS-03-006P-E1/240
70
6
480
1-3
32 15/16
22 1/2
16 1/2
NWHIS-03-006P-E1/480
70
12
240
1-3
42 15/16
32 1/2
26 1/2
NWHIS-03-012P-E1/240
80
12
480
1-3
42 15/16
32 1/2
26 1/2
NWHIS-03-012P-E1/480
80
18
240
1-3
55 7/16
45
39
NWHIS-03-018P-E1/240
98
18
480
1-3
55 7/16
45
39
NWHIS-03-018P-E1/480
98
Series 06 — 5 inch, 150 lb 304 passivated stainless steel vessel, 6 INCOLOY elements
(45 W/In2) with side mounted thermostat (60 to 250°F) — 2" NPT pipe inlet and outlet
24
240
2-3
41 3/4
30
11 3/8
NWHIS-06-024P-E1/240
140
24
480
1-3
41 3/4
30
11 3/8
NWHIS-06-024P-E1/480
140
30
240
2-3
48 3/4
37
14 1/8
NWHIS-06-030P-E1/240
155
30
480
1-3
48 3/4
37
14 1/8
NWHIS-06-030P-E1/480
155
40
240
2-3
60 1/4
48 1/2
20 5/8
NWHIS-06-040P-E1/240
176
40
480
2-3
60 1/4
48 1/2
20 5/8
NWHIS-06-040P-E1/480
176
50
480
2-3
73 5/8
61 7/8
27 5/16
NWHIS-06-050P-E1/480
210
Series 18 — 8 inch, 150 lb 304 passivated stainless steel vessel, 18 INCOLOY
elements (45 W/In2) — 21/2" NPT pipe inlet and outlet
50
240
3-3
45 1/4
24 11/16
27 3/16
NWHIS-18-050P-E1/240
396
50
480
3-3
45 1/4
24 11/16
27 3/16
NWHIS-18-050P-E1/480
396
75
240
3-3
53 1/4
32 11/16
29 3/16
NWHIS-18-075P-E1/240
414
75
480
3-3
53 1/4
32 11/16
29 3/16
NWHIS-18-075P-E1/480
414
100
240
3-3
60 1/4
39 11/16
36 3/16
NWHIS-18-100P-E1/240
425
100
480
3-3
60 1/4
39 11/16
36 3/16
NWHIS-18-100P-E1/480
425
125
240
3-3
67 7/8
47 5/16
43 3/16
NWHIS-18-125P-E1/240
470
125
480
3-3
67 7/8
47 5/16
43 3/16
NWHIS-18-125P-E1/480
470
150
240
3-3
77 3/8
56 13/16
53 5/16
NWHIS-18-150P-E1/240
535
150
480
3-3
77 3/8
56 13/16
53 5/16
NWHIS-18-150P-E1/480
535
175
240
3-3
86 3/8
65 13/16
62 5/16
NWHIS-18-175P-E1/240
625
175
480
3-3
86 3/8
65 13/16
62 5/16
NWHIS-18-175P-E1/480
625
200
240
3-3
96 3/8
75 13/16
72 5/16
NWHIS-18-200P-E1/240
705
200
480
3-3
96 3/8
75 13/16
72 5/16
NWHIS-18-200P-E1/480
705
† Price are shown in RMB.
