SINGLE HAIRPIN ELEMENT RADIANT PROCESS HEATERS |
| URAD Series |
|
 |
|
|
|
|
|
¥
6,125.00
U-RAD-2/120V
|
| • |
0.80 to 7.2 kW
|
| • |
120, 208, 240, 275, 480V
|
| • |
1500°F Max. Sheath Temperature A
|
| • |
3/8" Dia. Incoloy® Sheath
|
| • |
3.66 kW/ft2
|
| • |
Applications
• Roll heating
• Shrink fitting
• Pre-heating glass for polishing, drying and sterilizing
• Fast moving webs and other applications in which high temperatures will not damage the materials.
|
View related products - Radiant Heaters
|
| |
|
|
|
 |
Features
Complete, ready-to-connect assembly with adjustable terminal housing, which permits easy interchange of elements to accommodate work of varying dimensions.
Power connections are made at one end, using high temperature wire.
Control. Radiant output may be accurately controlled with a temperature controller (See Section P).
Protective Grilles. Snap-in sections protect personnel and work from contact with hot elements.
Additional sizes and ratings are available. Contact OMEGALUX for price and availability.
| kW |
Volts |
Dim. In. |
Model No. |
Wt.
lbs. |
Model No.
Optional
Grille |
Replacement
Elements
|
| A |
B |
| 0.8 | 120 | 123/4 | 85/16 | U-RAD-2/120V | 4 | GR-800 | UTU-2 |
| 0.8 | 208 | 123/4 | 85/16 | U-RAD-2V/208V | 4 | GR-800 | UTU-2V |
| 0.8 | 240 | 123/4 | 85/16 | U-RAD-2/240V | 4 | GR-800 | UTU-2 |
| 1.1 | 120 | 157/8 | 117/16 | U-RAD-3/120V | 5 | GR-800 | UTU-3 |
| 1.1 | 208 | 157/8 | 117/16 | U-RAD-3V/208V | 5 | GR-800 | UTU-3V |
| 1.1 | 240 | 157/8 | 117/16 | U-RAD-3/240V | 5 | GR-800 | UTU-3 |
| 1.8 | 208 | 2313/16 | 193/8 | U-RAD-4V/208V | 7 | GR-2 | UTU-4V |
| 1.8 | 240 | 2313/16 | 193/8 | U-RAD-4/240V | 7 | GR-2 | UTU-4 |
| 1.8 | 480 | 2313/16 | 193/8 | U-RAD-4/480V | 7 | GR-2 | UTU-4 |
| 2.5 | 208 | 311/4 | 2613/16 | U-RAD-5V/208V | 8 | GR-3 | UTU-5V |
| 2.5 | 240 | 311/4 | 2613/16 | U-RAD-5/240V | 8 | GR-3 | UTU-5 |
| 2.5 | 480 | 311/4 | 2613/16 | U-RAD-5/480V | 8 | GR-3 | UTU-5 |
| 3 | 208 | 371/4 | 3213/16 | U-RAD-6V/208V | 10 | (2) GR-2 | UTU-6V |
| 3 | 240 | 371/4 | 3213/16 | U-RAD-6/240V | 10 | (2) GR-2 | UTU-6 |
| 3 | 480 | 371/4 | 3213/16 | U-RAD-6/480V | 10 | (2) GR-2 | UTU-6 |
| 3.6 | 208 | 433/8 | 3815/16 | U-RAD-7V/208V | 12 | GR-4 | UTU-7V |
| 3.6 | 240 | 433/8 | 3815/16 | U-RAD-7/240V | 12 | GR-4 | UTU-7 |
| 3.6 | 480 | 433/8 | 3815/16 | U-RAD-7/480V | 12 | GR-4 | UTU-7 |
| Caution: Hazard of fire. These radiant heaters must not be operated in the presence of flammable vapors, gases or combustible materials, without proper ventilation and/or other safety precautions either in compliance with the National Fire Protection Bulletin 86A entitled "Ovens and Furnaces" or the authority having jurisdiction. |
|
|
|
|
|
|
† Price are shown in RMB.
Ordering Example: (1) U-RAD-2/120V single U-shaped element heater, 0.8 kW, 120 V, ¥6,125.00
|
|
|
|
|
| |
|
