1/8 DIN Process Meter & Controller

DP25B Series

Click for larger image.

^¥ 3,525.00 DP25B-E

•	5-Year Warranty
•	4-Digit Three Color (Red, Green, Amber) Programmable LED Display
•	Built-In Excitation
•	Scaling in Wide Range of Engineering Units
•	Analog Output Optional
•	Dual Relays Optional
•	Peak Memory
•	Tare Button
View related products - Temperature & Process Meters, Industrial Timers and Counters

The DP25B process meter accepts a wide variety of DC voltage and current inputs to cover any typical process application. Standard features include a full 4-digit three color (Red, Green, & Amber) programmable LED display, easy front panel scaling to virtually any engineering units, selectable excitation of four voltages to work with most transducers and transmitters, front panel and remote tare function for weighing applications, and a hardware lockout to prevent unauthorized changes in setup. The meter also has the ability to change display brightness from high, medium and low. Four full digits and simplified scaling via the front-panel pushbuttons make it easy to set the display to read in any engineering units. All these standard features add up to an instrument with powerful capabilities at an extremely affordable price.

Order on www.omegaengineering.cn and 5% will be discounted when you checkout.

To Order (Specify Model Number)
All list prices are pre-VAT rate not including tax and shipping

Part Number	Availability	Price(RMB)	Description	Qty.

DP25B-E for use with Amplifier Voltage or Current Output Device

DP25B-E	2 Weeks	¥3,525.00	Input Meter (Voltage and Current) with excitation, basic unit	qty.

DP25B-E-A		¥4,560.00	Input Meter (Voltage and Current) with excitation, and Analog Output	qty.

DP25B-E-AR	8 Weeks	¥5,535.00	Input Meter (Voltage and Current) with excitation, Analog Output and Dual 5A Relays	qty.

DP25B-E-AI-R	8 Weeks	¥5,975.00	Input Meter (Voltage and Current) with excitation, Isolated Analog Output and Dual 5A Relays	qty.


DP25B-S for use with Load Cells, mV output Devices and Strain Bridges

DP25B-S	2 Weeks	¥3,525.00	Input Meter (Ratiometric Voltage and Current) with excitation, basic unit	qty.

DP25B-S-A	8 Weeks	¥4,560.00	Input Meter (Ratiometric Voltage and Current) with excitation, and Analog Output	qty.

DP25B-S-AR	8 Weeks	¥5,845.00	Input Meter (Ratiometric Voltage and Current) with excitation, Analog Output and Dual 5A Relays	qty.

DP25B-S-AI-R	4 Weeks	¥5,655.00	Input Meter (Ratiometric Voltage and Current) with excitation, Isolated Analog Output and Dual 5A Relays	qty.

† Price are shown in RMB.

Note: Power Options are not field installable. All units come complete with a operator’s manual.

Part Number Builder

	(1)	(2)	(3)
D D P P 2 2 5 5 B B - -
Qty:

Option Descriptions

(1)

TYPE

Select
E for Process voltage and current inputs
S for Strain gage bridge or process inputs

(2)

Power Options

Select
for 115 Vac power leave blank
-230 for 230 Vac power
-DC10/32 for 10 to 32 Vdc power

(3)

Output Options

Select
for no options leave blank
-A for scaleable analog output
-R for dual alarm relays
-AR for analog and relay options
-AI-R for isolated analog outputs and relay options

NOTE: All combinations may not be valid, check spec sheet for valid part numbers.

Related Links - Manual, Related Products

Product Manual

Download DP25-E and DP25B-E - 1/8 DIN Process Panel Meter

Download DP25-E and DP25B-E - Quick Start Manual for DP25-E Process Meter

Download DP25-S and DP25B-S - Strain Gage Panel Meter Full Manual

Download DP25-S and DP25B-S - Strain Gage Meter Quick Start Manual
